IKOtile BOND 7
IKOtile BOND 7 is a traditional and attractive roof with timeless effect.
The IKOtile BOND 7 profile is designed to get the same appearance of the traditional clay roof style, with the additional benefits of steel roofing. Because of the downturned front and the upturned rear edges, the panels have a strong overlapping and interlocking tile covering, which provides an excellent durability, protection and resistance to wind lift or other extreme weather conditions.
The IKOtile BOND 7 is an eight tile, stone-coated panel pressed from a high grade of protective layer and is available in a wide selection of colours to enhance any exterior colour scheme.
SPECIFICATIONS:
| in METRICS | in IMPERIALS | |
| Minimum pitch | 10° | 2/12 |
| Maximum pitch | 90° | vertical |
| Size – overall* | 1335 x 415 mm | 52.64″ x 16.34″ |
| Size – cover* | 1270 x 370 mm | 50″ x 14.57″ |
| Gauge of steel** | 0,45 mm | 26 gauge |
| Linear cover width* | 1270 mm | 50″ |
| Cover* | 2,13 pc/m² | 19.77 pc/square |
| Cover of a panel* | 0,47 m² | 5.06 ft² |
| Weight per panel* | 3,18 kg | 7 lb |
* The measurements and the weight may vary slightly by the finish that is added to the panel.
** Steel thickness according to the EN 10346.
QUARTZ STANDARD COLORS:
